| Folded Size: |
| Height: |
0.96m |
| Width: |
0.52m |
| Depth: |
0.20m |
| Weight: |
9.5kg |
|
| Carrying Capacity: |
136kg
|
| Frame construction: |
Aluminium tubing
and section to BS 1474 : 1987 |
| Hammock seat: |
Flame
retardant woven reinforced nylon, coated with
PVC |
| Head Restraint:
|
(BS 3424 & BS 5438
refer see separate data sheet for full details) |
| Safety Belt: |
Side release
buckle with 50mm wide webbing |
| Front wheels: |
152.4mm Dia with 12.7mm Bore, black rubber tyre
with a minimum total load capacity of 110kg. |
| Rear wheels: |
50mm Dia swivel castor, grey rubber tyre
with a minimum total load capacity of 80kg. |
| Maintenance: |
Refer to Servicare Service
|
| Practise:
|
During fire drills minimum) more if possible |
| Limitations:
|
Designed to be
used on straight stairways, with a gradient
between 28 - 39 degrees |
| Kickstand: |
Foot operation
only |
| Training: |
Trained staff recommended
|
| Folded Size: |
| Height: |
0.98m |
| Width: |
0.40m |
| Depth: |
0.42m |
| Weight: |
12.5kg |
|
| Carrying Capacity: |
Maximum payload 136kg
|
| Frame construction: |
Aluminium tubing and section to BS 1474 : 1987
|
| Hammock seat: |
Flame resistant vinyl coated fabric |
| Head Restraint:
|
(BS 5822 Pt 1 refer see separate data sheet for full details) |
| Front & rear lifting facility:
|
Front fixed, rear folding |
| Safety Belt: |
Side release buckle with 50mm wide webbing |
| Front wheels: |
152.4mm Dia with 12.7mm Bore, black rubber tyre with a minimum total load capacity of 110kg |
| Rear wheels: |
50mm Dia swivel castor, grey rubber tyre with a minimum total load capacity of 80kg |
| Maintenance: |
Refer to Servicare Service
|
| Practise:
|
During fire drills minimum) more if possible |
| Limitations:
|
Designed to be
used on straight stairways, with a gradient
between 28 - 39 degrees |
| Kickstand: |
Foot operation
only |
| Training: |
Trained staff recommended
|
| Folded Size: |
| Height: |
0.98m |
| Width: |
0.60m |
| Depth: |
0.30m |
| Weight: |
11kg |
|
| Carrying Capacity: |
Maximum payload 150kg
|
| Frame construction: |
Aluminium tubing and section to BS 1474 : 1987 |
| Hammock seat: |
Flame resistant vinyl coated fabric |
| Head Restraint:
|
(BS 3424 & BS 5438 refer - see separate data sheet for full details) |
| Front & rear lifting facility:
|
Front fixed, rear folding |
| Safety Belt: |
Side release buckle with 50mm wide webbing |
| Front wheels: |
152.4mm Dia with 12.7mm Bore, black rubber tyre with a minimum total load capacity of 110kg |
| Rear wheels: |
50mm Dia swivel castor, grey rubber tyre with a minimum total load capacity of 80kg |
| Maintenance: |
Refer to Servicare Service
|
| Practise:
|
During fire drills minimum) more if possible |
| Limitations:
|
Designed to be
used on straight stairways, with a gradient
between 28 - 39 degrees |
| Kickstand: |
Foot operation
only |
| Training: |
Trained staff recommended
|
